उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| रंग: | हरी | वारंटी: | 24 महीने |
|---|---|---|---|
| प्रमाणपत्र: | सीई और आईएसओ | वेल्डिंग मानक: | DVS2207 |
| वेल्डिंग सामग्री: | HDPE PP PVDF PPH | नाम: | बट फ्यूजन वेल्डिंग मशीन |
| आवेदन: | जल आपूर्ति | सामग्री: | स्टील और एल्युमीनियम |
| ब्रांड: | एमएम-टेक | वेल्डिंग रेंज: | 630-1200एमएम |
| प्रमुखता देना: | Effecitve hdpe welding machines,1000mm hdpe welding machines,Water Supply hdpe welding machines |
||
Overview:
HDPE Butt Fusion Welding Machines, which usually used to weld thermoplastic pipes like PP and PE, consists of three parts:
Machine Chasis: The intergral frame features a quick and detachable structure, facilitating rapid maintenance and repair.
Heating Plate & Trimmer: Ergonomic operation handle designed in accordance with ergonomic principles.
Power Station: Robust hydraulic power with a maximum system pressure of up to 140 bar.
Technical Parameters:
| Welding Range O.D. | 630-1000 MM | Welding Range Inch | 24''-42''IPS |
| Power Supply |
380V ±10%, 50/60HZ |
TEMPERATURE RANGE |
MAX. 280 °C |
|
HEATER POWER |
17.5 KW |
PACKING DIMENSION |
2550*1850*1800 MM |
|
TRIMMER POWER |
3.0 KW |
1600*1150*1900 MM |
|
|
PUMP POWER |
2.2 KW |
800*350*400 MM |
|
|
WORKING PRESSURE RANGE |
0 - 140 BAR |
GROSS WEIGHT |
2318 KGS |
Welding Materials and Types:
High-quality butt fusion welding machines are designed for welding HDPE, PP, PPH, PVDF, and PPR pipes across various industries, including water supply, irrigation, drainage, gas, water treatment, mining, and chemical plants.
Application:
Advantages:
These thermofusion welding machines are manufactured in strict compliance with the ISO 12176 standard and comply with the DVS 2207 welding standard. Additionally, they offer customization options to meet the ISO 21307 and ASTM F2620 high-force standards
